The COMS Grading Scheme: Graded Features
Cotton wool spots (soft exudates)
Superficial white, pale yellow-white or grayish-white areas with ill-defined (feathery) edges, frequently showing striations parallel to the nerve fiber layer are the lesions included. These are distinct from the normal pattern of nerve fiber striations often seen along the superotemporal and inferotemporal arcades.
Severity
click on image for higher resolution image click on your browser's "back" button to return to this page |
| None: not present |
Mild: total area less than 1/2 disc area (standard photograph 1)
|
Moderate: total area more than 1/2 disc area, but less than 1 disc area (standard photograph 2)
|
| Severe: total area more than 1 disc area |
